Box Reveal — Free HTML CSS JS Panel Wipe Reveal Snippet
Box Reveal · Animations · Plain HTML, CSS & JS · Live preview
Copy & paste
Source Code
<div class="br-stage" id="brStage">
<div class="br-line" style="--d:0"><span class="br-cover"></span><h1>Design that moves</h1></div>
<div class="br-line" style="--d:1"><span class="br-cover"></span><p class="br-sub">A colored panel sweeps away to reveal each line.</p></div>
<div class="br-line" style="--d:2"><span class="br-cover"></span><a href="#" class="br-btn">Get started →</a></div>
<button type="button" class="br-replay" id="brReplay">↻ Replay</button>
</div>*{box-sizing:border-box;margin:0;padding:0}
body{font-family:system-ui,-apple-system,sans-serif;background:#0a0a14;color:#fff;display:flex;justify-content:center;align-items:center;min-height:100vh;padding:24px}
.br-stage{max-width:560px}
.br-line{position:relative;display:inline-block;overflow:hidden;margin-bottom:14px}
.br-line h1{font-size:clamp(34px,7vw,60px);font-weight:900;letter-spacing:-.03em}
.br-sub{font-size:16px;color:#9a9ac0;max-width:420px;line-height:1.5}
.br-btn{display:inline-block;background:#6366f1;color:#fff;text-decoration:none;font-weight:700;font-size:15px;padding:12px 22px;border-radius:11px}
/* The content starts invisible; a colored cover sweeps right, then back left,
revealing the content as it retreats — the classic box reveal. */
.br-line h1,.br-line .br-sub,.br-line .br-btn{opacity:0}
.br-cover{position:absolute;inset:0;background:#6366f1;transform:scaleX(0);transform-origin:left;z-index:1}
.br-stage.play .br-line h1,.br-stage.play .br-line .br-sub,.br-stage.play .br-line .br-btn{animation:brShow 0s linear forwards;animation-delay:calc(var(--d) * .18s + .42s)}
.br-stage.play .br-cover{animation:brSweep .85s cubic-bezier(.7,0,.3,1) forwards;animation-delay:calc(var(--d) * .18s)}
@keyframes brSweep{0%{transform:scaleX(0);transform-origin:left}50%{transform:scaleX(1);transform-origin:left}50.1%{transform-origin:right}100%{transform:scaleX(0);transform-origin:right}}
@keyframes brShow{to{opacity:1}}
.br-replay{margin-top:14px;background:rgba(255,255,255,.06);border:1px solid rgba(255,255,255,.14);color:#cfcfe0;font-family:inherit;font-size:13px;font-weight:600;padding:9px 16px;border-radius:999px;cursor:pointer}var stage = document.getElementById('brStage');
function play() {
stage.classList.remove('play');
// Force reflow so re-adding the class restarts the animations.
void stage.offsetWidth;
stage.classList.add('play');
}
// Reveal when the stage scrolls into view (once), and on replay click.
var io = new IntersectionObserver(function (entries) {
entries.forEach(function (e) { if (e.isIntersecting) { play(); io.disconnect(); } });
}, { threshold: 0.4 });
io.observe(stage);
document.getElementById('brReplay').addEventListener('click', play);Extend with AI
Take This Snippet Further With AI
The AI prompt for this one is for Patreon supporters ($3 a month), along with a site with no ads. Supporters enter the passcode once and it is remembered in this browser.
What's included
Features
About this UI Snippet
Box Reveal — A Colored Panel Wipes Away to Reveal Text
Box reveal is the punchy entrance where a solid colored panel sweeps across a line of text — growing from one side, then retreating to the other — and the text is revealed in its wake. Stacked across several lines with a stagger, it makes a headline arrive with confidence. This snippet builds it with plain HTML, CSS, and a little vanilla JavaScript for scroll triggering and replay.
The sweep in one keyframe
Each line has a .br-cover panel and the content beneath it. The brSweep keyframe drives the whole reveal by animating scaleX and flipping transform-origin at the midpoint: from 0 to 1 it grows from the left (covering the line), and at exactly 50.1% the origin switches to the right so from 1 back to 0 it shrinks toward the right (uncovering the line). That origin flip mid-animation is the trick that makes one panel both wipe on and wipe off in a single continuous motion, sweeping across the text.
Revealing the content at the right moment
The text underneath starts at opacity: 0 and is flipped to visible by a zero-duration brShow animation whose animation-delay is timed to the panel's midpoint — the instant the cover fully overlaps the line. So the content becomes visible while hidden behind the panel, and is then exposed as the panel retreats. Timing the reveal to the cover's peak is what prevents any flash of text before the wipe or a gap after it.
Per-line stagger
Each line carries a --d index, and both the sweep and the reveal use animation-delay: calc(var(--d) * .18s ...), so line 0 goes first, line 1 follows 180ms later, and so on. The cascade makes the headline, subtext, and button arrive in sequence rather than together, which reads as deliberate and polished. The whole sequence is driven by CSS; the index is the only per-line input.
Scroll-triggered, and replayable
An IntersectionObserver starts the reveal when the stage is 40% in view, then disconnects so it fires once on scroll. A replay button re-runs it by removing the .play class, forcing a reflow with void offsetWidth, and re-adding the class — the standard way to restart CSS animations. That reflow is essential: without it the browser would batch the class removal and re-add and the animations would not replay.
Why CSS over JS animation
Driving the wipe with a single keyframe and an origin flip keeps it on the compositor and makes the stagger a matter of calc delays — no per-frame scripting, no animation library. JavaScript only decides when to start and restart.
Customizing it
Recolor the cover panels (or give each line its own color), change the sweep duration and easing for a snappier or smoother wipe, adjust the .18s stagger, or change the sweep direction by editing the origin flip. Apply it to images or cards, not just text. Pair it with a text generate reveal or a shiny text badge for a coordinated intro.
Step by step
How to Use
- 1Paste HTML, CSS, and JSLines of content sit hidden behind colored panels.
- 2Scroll it into viewPanels sweep across and retreat, revealing each line.
- 3Watch the staggerHeadline, subtext, and button arrive in sequence.
- 4Click ReplayThe reveal re-runs from the start.
- 5Recolor the panelsChange the cover color per line.
- 6Tune the timingAdjust the sweep speed and the stagger.
Real-world uses
Common Use Cases
--d index.Got questions?
Frequently Asked Questions
The brSweep keyframe animates scaleX from 0 to 1 with the transform-origin on the left (growing to cover the line), then at 50.1% it switches the origin to the right so scaleX goes from 1 back to 0, shrinking toward the right and uncovering the line. Flipping the origin at the midpoint is what turns one panel into a single continuous wipe across the text.
The content starts at opacity 0 and is flipped visible by a zero-duration animation whose delay matches the panel's midpoint — when the cover fully overlaps the line. So the text becomes visible while still hidden behind the panel and is then exposed as the panel retreats, which avoids any flash before the wipe or gap after it.
Each line carries a --d index, and both the sweep and the reveal use animation-delay: calc(var(--d) * .18s + ...). So line 0 starts first, line 1 follows 180ms later, and so on. The cascade is entirely CSS, with the index as the only per-line input, making the headline, subtext, and button arrive in sequence.
It removes the play class, reads stage.offsetWidth to force a synchronous reflow, then re-adds the class. The reflow makes the browser register the removal before the re-add, so the CSS animations restart. Without forcing the reflow, the two class changes would be batched and the animation would not replay.
Render the lines with their index as a --d style and toggle a play class from state, triggered by an IntersectionObserver in a mount effect. For replay, briefly remove and re-add the class (or change a key to remount). The keyframes are pure CSS. In Tailwind, define the sweep and show animations in the config and apply staggered delays with arbitrary calc values.
