PDF.js Viewer with Thumbnails, Zoom and Rotate — Free JavaScript Snippet

<div class="pv">
  <div class="pv-toolbar" role="toolbar" aria-label="PDF controls">
    <label class="pv-open">Open PDF<input type="file" id="pvFile" accept="application/pdf"></label>
    <span class="pv-sep"></span>
    <button type="button" id="pvPrev" aria-label="Previous page">‹</button>
    <label class="pv-page"><input id="pvNum" type="number" min="1" value="1" aria-label="Page number"> / <span id="pvCount">–</span></label>
    <button type="button" id="pvNext" aria-label="Next page">›</button>
    <span class="pv-sep"></span>
    <button type="button" id="pvOut" aria-label="Zoom out">−</button>
    <select id="pvZoom" aria-label="Zoom level">
      <option value="fit">Fit width</option><option value="0.5">50%</option><option value="0.75">75%</option>
      <option value="1">100%</option><option value="1.25">125%</option><option value="1.5">150%</option><option value="2">200%</option>
    </select>
    <button type="button" id="pvIn" aria-label="Zoom in">+</button>
    <button type="button" id="pvRot" aria-label="Rotate 90 degrees">⟳</button>
    <span class="pv-name" id="pvName"></span>
  </div>
  <div class="pv-body">
    <nav class="pv-thumbs" id="pvThumbs" aria-label="Page thumbnails"></nav>
    <div class="pv-stage" id="pvStage" tabindex="0" aria-label="Page view"><canvas id="pvCanvas"></canvas></div>
  </div>
</div>

*{box-sizing:border-box;margin:0;padding:0}
body{font-family:system-ui,-apple-system,sans-serif;background:#1f2937;color:#e5e7eb;height:100vh;padding:14px;overflow:hidden}
.pv{height:100%;display:flex;flex-direction:column;max-width:1200px;margin:0 auto;background:#111827;border:1px solid #374151;border-radius:14px;overflow:hidden}
.pv-toolbar{display:flex;align-items:center;gap:6px;padding:8px 10px;background:#0b1220;border-bottom:1px solid #374151;flex-wrap:wrap}
.pv-toolbar button,.pv-toolbar select,.pv-open{background:#1f2937;color:#e5e7eb;border:1px solid #374151;border-radius:7px;height:30px;min-width:30px;padding:0 8px;font:600 13px system-ui;cursor:pointer}
.pv-toolbar button:disabled{opacity:.35;cursor:default}
.pv-open{display:inline-flex;align-items:center;background:#2563eb;border-color:#2563eb}
.pv-open input{position:absolute;width:1px;height:1px;opacity:0}
.pv-open:focus-within,.pv-toolbar :focus-visible{outline:2px solid #60a5fa;outline-offset:1px}
.pv-page{display:flex;align-items:center;gap:5px;font-size:13px}
.pv-page input{width:46px;height:30px;background:#1f2937;color:#e5e7eb;border:1px solid #374151;border-radius:7px;text-align:center;font:600 13px system-ui}
.pv-sep{width:1px;height:20px;background:#374151;margin:0 4px}
.pv-name{margin-left:auto;font-size:12px;color:#9ca3af;overflow:hidden;text-overflow:ellipsis;white-space:nowrap;max-width:260px}
.pv-body{flex:1;display:flex;min-height:0}
.pv-thumbs{width:150px;flex:0 0 auto;overflow-y:auto;padding:10px;border-right:1px solid #374151;display:flex;flex-direction:column;gap:10px;scrollbar-width:thin}
@media (max-width:640px){.pv-thumbs{display:none}}
.pv-thumbs button{background:none;border:2px solid transparent;border-radius:6px;padding:3px;cursor:pointer;color:#9ca3af;font:600 11px system-ui}
.pv-thumbs button canvas{width:100%;display:block;background:#fff;border-radius:2px}
.pv-thumbs button[aria-current="page"]{border-color:#60a5fa;color:#e5e7eb}
.pv-thumbs button:focus-visible{outline:2px solid #60a5fa}
.pv-stage{flex:1;overflow:auto;padding:18px;display:grid;place-items:start center;background:#374151;scrollbar-width:thin}
.pv-stage:focus-visible{outline:2px solid #60a5fa;outline-offset:-2px}
#pvCanvas{background:#fff;box-shadow:0 10px 30px rgba(0,0,0,.45)}

pdfjsLib.GlobalWorkerOptions.workerSrc = 'https://cdn.jsdelivr.net/npm/[email protected]/build/pdf.worker.min.js';

var pdf = null, pageNum = 1, zoom = 'fit', rotation = 0, renderTask = null;
var currentScale = 1; // the scale actually used by the last render (fit width included)
var canvas = document.getElementById('pvCanvas');
var stage = document.getElementById('pvStage');
var thumbs = document.getElementById('pvThumbs');

// A sample document built with jsPDF so the viewer opens with something to
// show and no network request for a file.
function sampleBytes() {
  var doc = new jspdf.jsPDF({ unit: 'pt', format: 'a4' });
  var colors = [[37, 99, 235], [220, 38, 38], [5, 150, 105], [217, 119, 6], [124, 58, 237]];
  var titles = ['Field Guide to Web Fonts', 'Chapter 1: Anatomy', 'Chapter 2: Loading', 'Chapter 3: Performance', 'Index'];
  titles.forEach(function (title, i) {
    if (i) doc.addPage(i === 3 ? 'a4' : 'a4', i === 3 ? 'landscape' : 'portrait');
    var W = doc.internal.pageSize.getWidth(), H = doc.internal.pageSize.getHeight();
    doc.setFillColor.apply(doc, colors[i]);
    doc.rect(0, 0, W, 90, 'F');
    doc.setTextColor(255, 255, 255);
    doc.setFont('helvetica', 'bold'); doc.setFontSize(24);
    doc.text(title, 40, 58);
    doc.setTextColor(55, 65, 81); doc.setFont('helvetica', 'normal'); doc.setFontSize(11);
    var para = 'Typography on the web is a negotiation between design intent and the realities of network, rendering and device. ';
    doc.text(doc.splitTextToSize(para.repeat(9), W - 80), 40, 130);
    doc.setDrawColor.apply(doc, colors[i]); doc.setLineWidth(2);
    doc.roundedRect(40, H - 220, W - 80, 140, 8, 8);
    doc.setFontSize(13); doc.setTextColor.apply(doc, colors[i]);
    doc.text(i === 3 ? 'This page is landscape' : 'Figure ' + (i + 1), 60, H - 185);
    doc.setFontSize(9); doc.setTextColor(156, 163, 175);
    doc.text(String(i + 1), W / 2, H - 28, { align: 'center' });
  });
  return doc.output('arraybuffer');
}

async function open(data, name) {
  if (pdf) pdf.destroy();
  pdf = await pdfjsLib.getDocument({ data: data }).promise;
  pageNum = 1; rotation = 0;
  document.getElementById('pvCount').textContent = pdf.numPages;
  document.getElementById('pvNum').max = pdf.numPages;
  document.getElementById('pvName').textContent = name;
  buildThumbs();
  render();
}

async function buildThumbs() {
  thumbs.innerHTML = '';
  var doc = pdf;
  for (var n = 1; n <= doc.numPages; n++) {
    var page = await doc.getPage(n);
    if (doc !== pdf) return; // a different file was opened meanwhile
    var vp = page.getViewport({ scale: 110 / page.getViewport({ scale: 1 }).width });
    var c = document.createElement('canvas');
    c.width = vp.width; c.height = vp.height;
    var b = document.createElement('button');
    b.type = 'button';
    b.setAttribute('aria-label', 'Go to page ' + n);
    b.dataset.n = n;
    b.appendChild(c);
    b.insertAdjacentHTML('beforeend', '<div>' + n + '</div>');
    thumbs.appendChild(b);
    await page.render({ canvasContext: c.getContext('2d'), viewport: vp }).promise;
  }
  markThumb();
}

function markThumb() {
  thumbs.querySelectorAll('button').forEach(function (b) {
    if (Number(b.dataset.n) === pageNum) { b.setAttribute('aria-current', 'page'); b.scrollIntoView({ block: 'nearest' }); }
    else b.removeAttribute('aria-current');
  });
}

async function render() {
  if (!pdf) return;
  var page = await pdf.getPage(pageNum);
  // "Fit width" depends on rotation: a rotated page is as wide as it was tall.
  var base = page.getViewport({ scale: 1, rotation: rotation });
  var scale = zoom === 'fit' ? (stage.clientWidth - 36) / base.width : Number(zoom);
  currentScale = scale;
  var dpr = window.devicePixelRatio || 1;
  var vp = page.getViewport({ scale: scale * dpr, rotation: rotation });
  // Cancel a render still in progress before starting another on the same
  // canvas; two renders drawing at once produce a garbled page.
  if (renderTask) { renderTask.cancel(); try { await renderTask.promise; } catch (e) {} }
  canvas.width = vp.width;
  canvas.height = vp.height;
  canvas.style.width = (vp.width / dpr) + 'px';
  canvas.style.height = (vp.height / dpr) + 'px';
  renderTask = page.render({ canvasContext: canvas.getContext('2d'), viewport: vp });
  try { await renderTask.promise; } catch (e) { if (e.name !== 'RenderingCancelledException') throw e; }
  renderTask = null;
  document.getElementById('pvNum').value = pageNum;
  document.getElementById('pvPrev').disabled = pageNum <= 1;
  document.getElementById('pvNext').disabled = pageNum >= pdf.numPages;
  markThumb();
}

function go(n) { if (!pdf) return; pageNum = Math.min(pdf.numPages, Math.max(1, n)); render(); }
var LEVELS = [0.5, 0.75, 1, 1.25, 1.5, 2];
function stepZoom(dir) {
  // From "fit width", step relative to the scale fit actually produced.
  var current = currentScale;
  var next = dir > 0 ? LEVELS.find(function (l) { return l > current + 0.01; }) : LEVELS.slice().reverse().find(function (l) { return l < current - 0.01; });
  if (next === undefined) return;
  zoom = String(next);
  document.getElementById('pvZoom').value = zoom;
  render();
}

document.getElementById('pvPrev').addEventListener('click', function () { go(pageNum - 1); });
document.getElementById('pvNext').addEventListener('click', function () { go(pageNum + 1); });
document.getElementById('pvNum').addEventListener('change', function (e) { go(Number(e.target.value) || 1); });
document.getElementById('pvZoom').addEventListener('change', function (e) { zoom = e.target.value; render(); });
document.getElementById('pvIn').addEventListener('click', function () { stepZoom(1); });
document.getElementById('pvOut').addEventListener('click', function () { stepZoom(-1); });
document.getElementById('pvRot').addEventListener('click', function () { rotation = (rotation + 90) % 360; render(); });
thumbs.addEventListener('click', function (e) { var b = e.target.closest('button'); if (b) go(Number(b.dataset.n)); });
stage.addEventListener('keydown', function (e) {
  if (e.key === 'ArrowRight' || e.key === 'PageDown') { e.preventDefault(); go(pageNum + 1); }
  if (e.key === 'ArrowLeft' || e.key === 'PageUp') { e.preventDefault(); go(pageNum - 1); }
  if (e.key === '+' || e.key === '=') stepZoom(1);
  if (e.key === '-') stepZoom(-1);
});
var rt;
window.addEventListener('resize', function () { if (zoom === 'fit') { clearTimeout(rt); rt = setTimeout(render, 120); } });

document.getElementById('pvFile').addEventListener('change', function (e) {
  var f = e.target.files[0];
  if (!f) return;
  f.arrayBuffer().then(function (buf) { return open(new Uint8Array(buf), f.name); })
    .catch(function (err) { document.getElementById('pvName').textContent = 'Could not open ' + f.name + ': ' + err.message; });
});

open(new Uint8Array(sampleBytes()), 'field-guide-sample.pdf');
