Scroll-Triggered GLB Model Carousel — Free GSAP ScrollTrigger + Three.js Gallery Snippet

<section class="gcs-intro"><h1>Scroll through a real gallery of glTF models</h1><p>Three real .glb models slide through one turntable as you scroll — drag to orbit whichever one is currently on stage.</p></section>
<section class="gcs-pin" id="gcsPin">
  <canvas id="gcsCanvas"></canvas>
  <div class="gcs-dots" id="gcsDots">
    <span class="gcs-dot active" data-i="0"></span>
    <span class="gcs-dot" data-i="1"></span>
    <span class="gcs-dot" data-i="2"></span>
  </div>
  <div class="gcs-label" id="gcsLabel">Duck</div>
  <div class="gcs-hint">Drag to orbit · plain scroll always scrolls the page · Ctrl/Cmd + scroll to zoom</div>
  <div class="gcs-zoom">
    <span class="gcs-zoom-label">+</span>
    <input type="range" id="gcsZoom" class="gcs-zoom-slider" min="0" max="100" step="1" />
    <span class="gcs-zoom-label">&minus;</span>
  </div>
</section>
<section class="gcs-outro"><p>End of the gallery &mdash; scroll back up to bring the first model back on stage.</p></section>

*{box-sizing:border-box;margin:0;padding:0}
body{font-family:system-ui,-apple-system,sans-serif;color:#fff;background:#0a0b12}
.gcs-intro,.gcs-outro{min-height:70vh;display:flex;flex-direction:column;justify-content:center;align-items:center;text-align:center;gap:10px;padding:24px}
.gcs-intro h1{font-size:clamp(28px,6vw,50px);letter-spacing:-.02em}
.gcs-intro p,.gcs-outro p{color:#9aa0b8;font-size:15px;max-width:460px}
.gcs-pin{position:relative;height:100vh;overflow:hidden;background:radial-gradient(60% 60% at 50% 42%,#181c28,#0a0b12)}
#gcsCanvas{display:block;width:100%;height:100%;cursor:grab}
#gcsCanvas:active{cursor:grabbing}
.gcs-dots{position:absolute;top:26px;left:50%;transform:translateX(-50%);display:flex;gap:8px}
.gcs-dot{width:8px;height:8px;border-radius:50%;background:rgba(255,255,255,.22);transition:background .25s,transform .25s}
.gcs-dot.active{background:#5eead4;transform:scale(1.3)}
.gcs-label{position:absolute;top:58px;left:50%;transform:translateX(-50%);font-size:13px;font-weight:700;letter-spacing:.04em;color:#99f6e4;background:rgba(10,12,20,.55);padding:6px 16px;border-radius:999px;border:1px solid rgba(94,234,212,.3);backdrop-filter:blur(6px)}
.gcs-hint{position:absolute;left:50%;bottom:26px;transform:translateX(-50%);font-size:12px;font-weight:600;color:#b7c0da;background:rgba(10,12,20,.55);padding:8px 16px;border-radius:999px;backdrop-filter:blur(6px);border:1px solid rgba(255,255,255,.08)}
.gcs-zoom{position:absolute;right:22px;top:74px;bottom:74px;width:34px;display:flex;flex-direction:column;align-items:center;gap:8px;background:rgba(10,12,20,.55);border:1px solid rgba(255,255,255,.1);border-radius:999px;padding:10px 0;backdrop-filter:blur(6px)}
.gcs-zoom-label{font-size:13px;font-weight:700;color:#b7c0da;line-height:1;user-select:none}
.gcs-zoom-slider{flex:1;width:6px;-webkit-appearance:slider-vertical;writing-mode:vertical-lr;direction:rtl;accent-color:#5eead4;cursor:pointer}

gsap.registerPlugin(ScrollTrigger);

const canvas = document.getElementById('gcsCanvas');
const label = document.getElementById('gcsLabel');
const dots = Array.from(document.querySelectorAll('.gcs-dot'));

const renderer = new THREE.WebGLRenderer({ canvas, antialias: true, alpha: true });
renderer.setPixelRatio(Math.min(window.devicePixelRatio, 2));

const scene = new THREE.Scene();
const camera = new THREE.PerspectiveCamera(40, 1, 0.1, 50);
camera.position.set(0, 0.5, 4.2);

// OrbitControls only ever moves the CAMERA around a fixed turntable point.
// Scroll, below, only ever slides each model GROUP's own position and
// rotation. Two independent transforms on two independent kinds of
// objects, so dragging to orbit the current model and scrolling to swap
// models never fight over the same property.
const controls = new THREE.OrbitControls(camera, renderer.domElement);
controls.enableDamping = true;
controls.dampingFactor = 0.08;
controls.target.set(0, 0.2, 0);
controls.minDistance = 2;
controls.maxDistance = 9;

// OrbitControls' own wheel-zoom is turned off on purpose: left on, it calls
// preventDefault() on every wheel event over the canvas — including a plain
// scroll — which would silently swallow the page scroll this whole demo
// depends on. Zoom is reimplemented below as an explicit, opt-in gesture
// (a slider, and Ctrl/Cmd + scroll) instead of hijacking the default wheel.
controls.enableZoom = false;

const zoomSlider = document.getElementById('gcsZoom');

function setZoomDistance(distance) {
  const clamped = THREE.MathUtils.clamp(distance, controls.minDistance, controls.maxDistance);
  const offset = camera.position.clone().sub(controls.target);
  offset.setLength(clamped || 0.001);
  camera.position.copy(controls.target).add(offset);
  const t = (clamped - controls.minDistance) / (controls.maxDistance - controls.minDistance);
  zoomSlider.value = String(Math.round((1 - t) * 100));
}

setZoomDistance(camera.position.distanceTo(controls.target));

zoomSlider.addEventListener('input', () => {
  const t = 1 - Number(zoomSlider.value) / 100;
  setZoomDistance(controls.minDistance + t * (controls.maxDistance - controls.minDistance));
});

canvas.addEventListener('wheel', (e) => {
  if (!e.ctrlKey && !e.metaKey) return; // plain scroll always passes through to the page
  e.preventDefault();
  const current = camera.position.distanceTo(controls.target);
  setZoomDistance(current + e.deltaY * 0.01);
}, { passive: false });

scene.add(new THREE.AmbientLight(0x445066, 0.7));
const key = new THREE.DirectionalLight(0xffffff, 1.8);
key.position.set(4, 6, 5);
scene.add(key);
const fill = new THREE.DirectionalLight(0x5eead4, 0.4);
fill.position.set(-5, 2, 3);
scene.add(fill);

const ground = new THREE.Mesh(
  new THREE.CircleGeometry(4, 48),
  new THREE.MeshStandardMaterial({ color: 0x11141f, roughness: 1 })
);
ground.rotation.x = -Math.PI / 2;
ground.position.y = -0.75;
scene.add(ground);

// Three real, freely-licensed .glb files from Khronos' sample-asset
// repository — a genuine gallery of distinct models, not one model
// with three color variants.
const GALLERY = [
  { name: 'Duck', url: 'https://cdn.jsdelivr.net/gh/KhronosGroup/glTF-Sample-Assets@main/Models/Duck/glTF-Binary/Duck.glb', color: 0xfacc15 },
  { name: 'Antique Camera', url: 'https://cdn.jsdelivr.net/gh/KhronosGroup/glTF-Sample-Assets@main/Models/AntiqueCamera/glTF-Binary/AntiqueCamera.glb', color: 0xa78bfa },
  { name: 'BoomBox', url: 'https://cdn.jsdelivr.net/gh/KhronosGroup/glTF-Sample-Assets@main/Models/BoomBox/glTF-Binary/BoomBox.glb', color: 0x5eead4 },
];

// Each gallery entry gets its own wrapper Group, positioned on the same
// turntable circle 120 degrees apart. Scroll only ever rotates this whole
// turntable Group (never an individual model's own local transform), so
// swapping which model is "on stage" is just a rotation, not a visibility
// toggle or position swap.
const turntable = new THREE.Group();
scene.add(turntable);

const SLOT_RADIUS = 3.2;
const slots = GALLERY.map((_, i) => {
  const angle = (i / GALLERY.length) * Math.PI * 2;
  const slot = new THREE.Group();
  slot.position.set(Math.sin(angle) * SLOT_RADIUS, 0, Math.cos(angle) * SLOT_RADIUS - SLOT_RADIUS);
  turntable.add(slot);
  return slot;
});

function loadIntoSlot(entry, slot) {
  const loader = new THREE.GLTFLoader();
  loader.load(
    entry.url,
    (gltf) => {
      const model = gltf.scene;
      // Auto-fit rather than a hardcoded scale factor: different .glb
      // exports (and loader versions) can decode the same source asset at
      // wildly different raw sizes, so measuring the loaded geometry and
      // scaling it to a known target height is far more reliable than
      // guessing a magic number ahead of time.
      const box = new THREE.Box3().setFromObject(model);
      const size = box.getSize(new THREE.Vector3());
      const maxDim = Math.max(size.x, size.y, size.z) || 1;
      model.scale.setScalar(1.6 / maxDim);
      const fitted = new THREE.Box3().setFromObject(model);
      model.position.y += -0.75 - fitted.min.y;
      slot.add(model);
    },
    undefined,
    (err) => {
      // Honest failure state: if the CDN model can't load, swap in a
      // simple placeholder so that slot on the turntable is never empty.
      console.error('GLB failed to load for ' + entry.name + ', showing a placeholder instead:', err);
      const placeholder = new THREE.Mesh(
        new THREE.SphereGeometry(0.8, 24, 24),
        new THREE.MeshStandardMaterial({ color: entry.color, roughness: 0.5 })
      );
      placeholder.position.y = -0.1;
      slot.add(placeholder);
    }
  );
}

GALLERY.forEach((entry, i) => loadIntoSlot(entry, slots[i]));

// Scroll rotates the whole turntable Group by exactly one slot's worth of
// angle per gallery entry, mapping scroll progress directly onto which
// model is currently facing the camera — a pure, reversible function of
// scroll position, just like the single-model turntable snippet, applied
// here to which model is on stage rather than to one model's own spin.
const TOTAL_SLOTS = GALLERY.length;

ScrollTrigger.create({
  trigger: '#gcsPin',
  start: 'top top',
  end: '+=' + (TOTAL_SLOTS * 1300),
  pin: true,
  scrub: 0.45,
  onUpdate(self) {
    const raw = self.progress * (TOTAL_SLOTS - 1);
    turntable.rotation.y = (raw / TOTAL_SLOTS) * Math.PI * 2 * -1;
    const index = Math.min(TOTAL_SLOTS - 1, Math.round(raw));
    label.textContent = GALLERY[index].name;
    dots.forEach((d, i) => d.classList.toggle('active', i === index));
  },
});

function resize() {
  const w = canvas.clientWidth, h = canvas.clientHeight;
  renderer.setSize(w, h, false);
  camera.aspect = w / h;
  camera.updateProjectionMatrix();
}

function animate() {
  requestAnimationFrame(animate);
  controls.update();
  renderer.render(scene, camera);
}

resize();
window.addEventListener('resize', resize);
animate();
