Swipe-to-Reveal List Item Actions — Archive/Delete with Real Drag Physics
Swipe-to-Reveal List Item Actions (Archive / Delete) · Mobile · Plain HTML, CSS & JS · Live preview
Copy & paste
Source Code
<div class="demo">
<div class="phone-frame">
<div class="inbox-screen">
<div class="inbox-header">Inbox</div>
<ul class="swipe-list" id="swipeList">
<li class="swipe-item" data-id="1">
<div class="swipe-actions">
<button class="swipe-action archive" data-action="archive">Archive</button>
<button class="swipe-action delete" data-action="delete">Delete</button>
</div>
<div class="swipe-content">
<span class="swipe-avatar">MC</span>
<div class="swipe-text">
<span class="swipe-title">Mia Chen</span>
<span class="swipe-preview">Approved the design changes for the...</span>
</div>
</div>
</li>
<li class="swipe-item" data-id="2">
<div class="swipe-actions">
<button class="swipe-action archive" data-action="archive">Archive</button>
<button class="swipe-action delete" data-action="delete">Delete</button>
</div>
<div class="swipe-content">
<span class="swipe-avatar">SO</span>
<div class="swipe-text">
<span class="swipe-title">Sam Okoye</span>
<span class="swipe-preview">Can we move Thursday's sync to...</span>
</div>
</div>
</li>
<li class="swipe-item" data-id="3">
<div class="swipe-actions">
<button class="swipe-action archive" data-action="archive">Archive</button>
<button class="swipe-action delete" data-action="delete">Delete</button>
</div>
<div class="swipe-content">
<span class="swipe-avatar">JP</span>
<div class="swipe-text">
<span class="swipe-title">Jules Park</span>
<span class="swipe-preview">Here's the updated budget spreadsheet...</span>
</div>
</div>
</li>
</ul>
<p class="swipe-hint">Drag a row left to reveal actions. Drag with a mouse too — the interaction works with both touch and pointer input.</p>
</div>
</div>
</div>* { box-sizing: border-box; margin: 0; padding: 0; }
body { font-family: system-ui, sans-serif; background: #f8fafc; display: flex; align-items: center; justify-content: center; min-height: 100vh; padding: 24px; }
.demo { display: flex; }
.phone-frame { width: 300px; height: 480px; border-radius: 32px; border: 8px solid #0f172a; background: #0f172a; overflow: hidden; box-shadow: 0 30px 60px rgba(15,23,42,0.25); }
.inbox-screen { height: 100%; background: #fff; display: flex; flex-direction: column; }
.inbox-header { padding: 14px 16px; font-size: 14px; font-weight: 800; color: #111827; border-bottom: 1px solid #f1f5f9; flex-shrink: 0; }
.swipe-list { flex: 1; overflow-y: auto; list-style: none; }
.swipe-item { position: relative; overflow: hidden; border-bottom: 1px solid #f1f5f9; touch-action: pan-y; }
.swipe-actions { position: absolute; inset: 0; display: flex; justify-content: flex-end; }
.swipe-action { width: 76px; border: none; color: #fff; font-size: 11.5px; font-weight: 700; cursor: pointer; font-family: inherit; }
.swipe-action.archive { background: #f59e0b; }
.swipe-action.delete { background: #ef4444; }
.swipe-content {
position: relative;
display: flex; align-items: center; gap: 10px;
padding: 12px 16px;
background: #fff;
transform: translateX(0);
transition: transform 0.2s ease;
touch-action: pan-y;
}
.swipe-avatar { width: 34px; height: 34px; border-radius: 50%; background: #eef2ff; color: #4338ca; font-size: 11px; font-weight: 800; display: flex; align-items: center; justify-content: center; flex-shrink: 0; }
.swipe-text { display: flex; flex-direction: column; gap: 2px; min-width: 0; }
.swipe-title { font-size: 12.5px; font-weight: 700; color: #111827; }
.swipe-preview { font-size: 11.5px; color: #94a3b8; white-space: nowrap; overflow: hidden; text-overflow: ellipsis; }
.swipe-hint { padding: 10px 16px; font-size: 10.5px; color: #94a3b8; line-height: 1.5; flex-shrink: 0; }
.swipe-item.removing .swipe-content { transition: transform 0.22s ease, opacity 0.22s ease; opacity: 0; }
.swipe-item.removing { transition: max-height 0.22s ease 0.1s; max-height: 0 !important; }const ACTIONS_WIDTH = 152; // must match the combined width of the two action buttons
document.querySelectorAll('.swipe-item').forEach((item) => {
const content = item.querySelector('.swipe-content');
const actions = item.querySelectorAll('.swipe-action');
let startX = 0;
let currentX = 0;
let dragging = false;
let isOpen = false;
function setTranslate(x, animate) {
content.style.transition = animate ? 'transform 0.2s ease' : 'none';
content.style.transform = `translateX(${x}px)`;
}
content.addEventListener('pointerdown', (e) => {
dragging = true;
startX = e.clientX;
currentX = isOpen ? -ACTIONS_WIDTH : 0;
content.setPointerCapture(e.pointerId);
});
content.addEventListener('pointermove', (e) => {
if (!dragging) return;
const delta = e.clientX - startX;
// Clamp so the row can never be dragged past fully-open (revealing more
// than the actions' own width) or past fully-closed in the other
// direction — the drag always stays within the valid [-ACTIONS_WIDTH, 0]
// range no matter how far the pointer actually moves.
const next = Math.min(0, Math.max(-ACTIONS_WIDTH, currentX + delta));
setTranslate(next, false);
});
function endDrag(e) {
if (!dragging) return;
dragging = false;
const delta = e.clientX - startX;
const finalX = Math.min(0, Math.max(-ACTIONS_WIDTH, currentX + delta));
// Snap open or closed based on how far past the halfway point the drag
// ended — a genuine "flick" threshold, not requiring the user to drag
// the entire width before anything happens.
isOpen = finalX < -ACTIONS_WIDTH / 2;
setTranslate(isOpen ? -ACTIONS_WIDTH : 0, true);
}
content.addEventListener('pointerup', endDrag);
content.addEventListener('pointercancel', endDrag);
// Tapping an already-open row's content (rather than dragging) closes it —
// a natural way to dismiss revealed actions without needing to swipe back.
content.addEventListener('click', () => {
if (isOpen) {
isOpen = false;
setTranslate(0, true);
}
});
actions.forEach((btn) => {
btn.addEventListener('click', () => {
const action = btn.dataset.action;
if (action === 'delete') {
// Removing an item animates its height to zero after its content
// has already faded, rather than vanishing instantly — a smoother,
// more intentional-feeling removal than an abrupt DOM removal.
item.classList.add('removing');
setTimeout(() => item.remove(), 350);
} else {
content.style.background = '#fffbeb';
setTranslate(0, true);
isOpen = false;
setTimeout(() => { content.style.background = ''; }, 500);
}
});
});
});Extend with AI
Take This Snippet Further With AI
The AI prompt for this one is for Patreon supporters ($3 a month), along with a site with no ads. Supporters enter the passcode once and it is remembered in this browser.
What's included
Features
About this UI Snippet
Swipe-to-Reveal List Actions — Getting the Drag Physics Right
The swipe-left-to-reveal-actions pattern is familiar from every mobile mail and messaging app — but a convincing implementation depends on getting the *drag physics* right, not just sliding a panel a fixed distance on tap. This snippet tracks the actual pointer position throughout the gesture, clamps it to a valid range, and decides open-vs-closed based on how far the drag traveled relative to a real threshold — the same feel as a native swipe action.
The row's content follows the pointer exactly, not a preset animation
While dragging, setTranslate() is called on every pointermove with a position computed directly from the pointer's live delta — the row's content visually tracks the finger or cursor in real time, rather than snapping through a fixed pre-built animation the instant a swipe is detected. This is what makes the interaction feel physically connected to the gesture rather than merely triggered by it.
Clamping keeps the drag within a valid range, always
Math.min(0, Math.max(-ACTIONS_WIDTH, currentX + delta)) bounds every intermediate drag position between fully-closed (0) and fully-open (-ACTIONS_WIDTH, exactly the combined width of the two action buttons) — no matter how far past either edge the pointer actually travels. Without this clamp, a fast or long drag could push the content translateX far beyond the actions' actual width, either revealing empty space beyond the buttons or over-dragging in the closed direction into negative content overlap.
A genuine flick threshold, not "any drag opens it"
endDrag() decides whether to snap open or closed based on whether the final drag position passed the halfway point of ACTIONS_WIDTH — not whether *any* drag distance was registered at all. This matches how real native swipe interactions feel: a small, tentative drag that doesn't cross the threshold snaps back closed, while a more committed drag past the midpoint snaps fully open, giving the user forgiving, natural-feeling control rather than an all-or-nothing trigger.
Tapping open content closes it — a second, independent way back
Beyond dragging back to closed, a plain click on an already-open row's content also closes it. This matters because not every user will think to drag back; tapping the now-familiar visible content area to dismiss revealed actions is a common alternate expectation, and implementing it as a separate, simple click handler (checking isOpen first) covers that case without complicating the drag logic itself.
Delete animates height *after* the content fade completes, not simultaneously
The .removing class first fades the row's content opacity, and — via a CSS transition-delay on the outer <li>'s max-height — only *then* collapses the row's height to zero. Collapsing height and fading content at exactly the same time would look like the text is being physically squashed as it disappears; sequencing fade-then-collapse instead produces a cleaner, more intentional-feeling removal.
Step by step
How to Use
- 1Drag a row left with a mouse or touchThe row's content visually tracks the drag in real time, revealing the archive/delete actions underneath it as it slides.
- 2Release partway through a short dragIf you didn't drag past the halfway point of the actions' width, the row snaps back closed automatically.
- 3Release after dragging past the halfway pointThe row snaps fully open, staying revealed until you interact with it again.
- 4Tap the open row's content, or drag it back rightBoth close the row — tapping is a quick way to dismiss without needing to reverse the drag gesture.
- 5Tap "Delete"The row's content fades first, then its height smoothly collapses to zero before it's removed from the DOM.
Real-world uses
Common Use Cases
Got questions?
Frequently Asked Questions
Tracking the pointer's live position on every move makes the interaction feel physically connected to the gesture — the same feel users expect from native swipe actions on their phone, rather than a UI element that merely reacts to a swipe being detected after the fact.
Whether the final drag position passed the halfway point between fully-closed and fully-open (ACTIONS_WIDTH / 2) — a real threshold-based decision, not simply whether any dragging happened at all. This gives forgiving, natural-feeling control matching real native swipe interactions.
Yes — tapping anywhere on the open row's visible content closes it via a separate click handler, giving users a second, simpler way to dismiss the revealed actions besides reversing the drag gesture.
Fading the content first and only then collapsing the row's height (via a CSS transition-delay) avoids the visually awkward effect of text appearing to be physically squashed as the row shrinks — sequencing the two produces a cleaner, more intentional-feeling removal animation.
The drag position is clamped with Math.min/Math.max on every movement to stay within the valid [-ACTIONS_WIDTH, 0] range, so no amount of extra drag distance can push the row translation beyond fully-open or fully-closed — it simply stops moving once it hits either boundary.
Both — the interaction is built entirely on Pointer Events (pointerdown/pointermove/pointerup/pointercancel) with setPointerCapture, which unifies mouse, touch, and pen input under one API, so dragging with a mouse produces identical behavior to a finger swipe.
