Particle Swarm Loader — Randomized Orbiting Particles in HTML CSS JS
Particle Swarm Loader · Loaders · Plain HTML, CSS & JS · Live preview
Copy & paste
Source Code
<div class="ps-stage">
<div class="ps-field" id="psField" role="status" aria-label="Loading"><div class="ps-core"></div></div>
<p class="ps-hint">12 particles, each with its own radius, speed, and phase</p>
</div>*{box-sizing:border-box;margin:0;padding:0}
body{font-family:system-ui,-apple-system,sans-serif;background:#07070f;color:#8b90ab;min-height:100vh;display:flex;align-items:center;justify-content:center;padding:24px}
.ps-stage{display:flex;flex-direction:column;align-items:center;gap:18px}
.ps-field{position:relative;width:220px;height:220px}
.ps-core{position:absolute;top:50%;left:50%;width:14px;height:14px;margin:-7px 0 0 -7px;border-radius:50%;background:radial-gradient(circle at 35% 30%,#fff,#818cf8);box-shadow:0 0 22px 4px rgba(129,140,248,.7)}
.ps-particle{position:absolute;top:50%;left:50%;border-radius:50%;will-change:transform,opacity}
.ps-hint{font-size:12px;color:#5b6083}var field = document.getElementById('psField');
var COUNT = 12;
var colors = ['#818cf8', '#22d3ee', '#f472b6', '#34d399', '#fbbf24'];
var particles = [];
// Give every particle genuinely randomized orbit parameters — radius, angular
// speed, phase offset, and vertical eccentricity — instead of evenly spacing
// identical orbits. This is what turns a ring of dots into a swarm.
for (var i = 0; i < COUNT; i++) {
var el = document.createElement('div');
el.className = 'ps-particle';
var size = 4 + Math.random() * 6;
el.style.width = size + 'px';
el.style.height = size + 'px';
el.style.background = colors[i % colors.length];
el.style.boxShadow = '0 0 ' + (size * 1.6) + 'px ' + colors[i % colors.length];
field.appendChild(el);
particles.push({
el: el,
radius: 30 + Math.random() * 80, // per-particle orbit radius
speed: (0.4 + Math.random() * 1.4) * (Math.random() < 0.5 ? -1 : 1), // rad/s, mixed direction
phase: Math.random() * Math.PI * 2, // per-particle start angle
eccentricity: 0.55 + Math.random() * 0.45, // flattens the orbit into an ellipse
baseOpacity: 0.45 + Math.random() * 0.55,
});
}
var start = null;
function tick(ts) {
if (!start) start = ts;
var elapsed = (ts - start) / 1000;
particles.forEach(function (p) {
var angle = p.phase + elapsed * p.speed;
var x = Math.cos(angle) * p.radius;
var y = Math.sin(angle) * p.radius * p.eccentricity;
// Particles nearer the "front" of their ellipse (larger sin) appear
// slightly bigger and brighter, faking depth without a 3D engine.
var depth = (Math.sin(angle) + 1) / 2;
var scale = 0.7 + depth * 0.6;
p.el.style.transform = 'translate(' + x.toFixed(2) + 'px,' + y.toFixed(2) + 'px) scale(' + scale.toFixed(2) + ')';
p.el.style.opacity = (p.baseOpacity * (0.5 + depth * 0.5)).toFixed(2);
p.el.style.zIndex = String(Math.round(depth * 100));
});
requestAnimationFrame(tick);
}
requestAnimationFrame(tick);Extend with AI
Take This Snippet Further With AI
The AI prompt for this one is for Patreon supporters ($3 a month), along with a site with no ads. Supporters enter the passcode once and it is remembered in this browser.
What's included
Features
About this UI Snippet
Particle Swarm Loader — 12 Particles With Real Per-Particle Randomized Orbits

A ring loader like an orbit loader or dots loader typically animates a handful of evenly-spaced dots on identical circular paths — clean, but mechanical. A swarm reads differently: dozens of particles moving at their own pace on their own paths, converging and drifting apart unpredictably. This snippet builds that with 12 particles, each given genuinely randomized orbit parameters computed once at load and then animated every frame with real trigonometry — not CSS keyframes on a shared ring.
Per-particle randomized parameters
Each particle gets its own radius (30–110px), speed (0.4–1.8 rad/s, with roughly half orbiting clockwise and half counter-clockwise), phase (a random starting angle around the circle), and eccentricity (0.55–1, flattening the circular path into an ellipse of varying flatness). These are generated once with Math.random() when the particles are created, so no two particles trace the same path — a structural difference from a CSS @keyframes ring where every dot shares one rotation duration and only differs by a fixed animation-delay.
Real per-frame position math, not CSS rotation
A single requestAnimationFrame loop computes every particle's x/y position each frame from Math.cos(angle) * radius and Math.sin(angle) * radius * eccentricity, where angle advances by each particle's own speed times elapsed time. This is genuinely computed motion — the position exists as real numbers you could log, not an opaque CSS animation — which is what makes true per-particle randomization possible; CSS keyframes can't express twelve different radii and speeds without twelve separate keyframe blocks.
Faked depth from the ellipse
Because each orbit is flattened into an ellipse, particles on the "near" side of their path (where sin(angle) is largest) are scaled up slightly and given higher opacity and z-index, while particles on the "far" side shrink and fade. This single trick — deriving apparent depth from the same sine value that already drives vertical position — gives the swarm a pseudo-3D quality without any actual 3D transform or WebGL.
A genuine swarm, not a bigger ring
Twelve particles with independently randomized radius, direction, speed, and phase is meaningfully more complex than the 3–8 dot rings common elsewhere in this library: there is no repeating unit, no shared timing, and the pattern never exactly loops. Tune COUNT, the radius range, or the color palette to match your brand, and consider pairing it with a gradient progress bar for a companion determinate indicator once real progress is known.
Step by step
How to Use
- 1Paste HTML, CSS, and JS12 particles orbit a glowing core at independently randomized speeds.
- 2Watch for a full minuteNotice the pattern never exactly repeats — each particle has its own phase and speed.
- 3Change particle countEdit the COUNT constant to add or remove particles.
- 4Tune the orbit rangesAdjust the radius, speed, and eccentricity random ranges for a tighter or wider swarm.
- 5Recolor the paletteEdit the colors array to match your brand.
- 6Reuse the position mathThe angle/radius/eccentricity formula ports to canvas or SVG if you need thousands of particles.
Real-world uses
Common Use Cases
Got questions?
Frequently Asked Questions
A CSS-keyframe orbit ring rotates one shared element (or a few dots on it) using @keyframes, so every dot shares the same duration and only differs by animation-delay. Here, each of 12 particles has its own independently randomized radius, speed, direction, and phase computed once in JS, and every frame recalculates each particle's position from real cos/sin math — a structurally different, much less repetitive motion.
CSS keyframes can express a fixed number of named states per animation, which becomes unwieldy for 12+ particles each needing a unique radius and speed. Driving position from a requestAnimationFrame loop with real numbers means every parameter can be randomized independently and the same formula scales to any particle count without writing new keyframe blocks.
Each orbit is an ellipse (y is scaled by an eccentricity factor), so a particle at the "front" of its ellipse has a larger sine value than one at the "back". That same sine value drives a size scale and opacity boost, so front particles appear closer and back particles appear farther — a 2D trick that reads as depth without any actual perspective transform.
12 DOM-element particles with a requestAnimationFrame loop is well within budget for any modern browser. If you need hundreds or thousands, port the same angle/radius/eccentricity formula to a <canvas> 2D context or WebGL point sprites instead of individual DOM elements, since DOM updates get costly at very high counts.
Generate the particle parameter array once (in useMemo, a computed ref, or a component field) so it is not re-randomized on every re-render, then run the requestAnimationFrame loop in a mount effect with cleanup that cancels the frame on unmount. Update each particle's transform via a ref rather than through component state to avoid a re-render every frame.
